Working environment:
Voltage: DC +8 V-+15 V (standard 12V)
Current: when Do not drive electric lock ≤ 70mA
Temperature: 0 °C -70 °C
Humidity: 30% -90%
5 kinds of open-door mode:
card to open the door
Password to open the door
card + password to open the door
card + card to open the door
password + password to open the door
Features:
500 people registered capacity, high cost performance, digging every hardware resources.
Quick issuers mode, whether it is registered general card or the card with a password can be registered, passwords input setup by cardholders their own input in the first timedoor state dete-ction, only after close stable then startlocking signal, preventing the door in the swing when the latch, resulting in on the impact of electric locking bolt. with door magnetism interface, with the alarm when open the door violence.
Wiring port definition and performance:
Indicator:
Red light: Power instructions the red Power is red light means normal. Green light: the green light, said unlock, put out that state lock. Yellow light: yellow light flashing, said waiting for keyboard input, always yellow light open said that the programming mode.
