Access Control RFID Card Reader With Keypad PY-CR49

Access Control RFID Card Reader With Keypad PY-CR49

  • Size:120×56×20(mm)
  • Color: BLACK
  • Working Voltage:DC 9~12V
  • Working Curren: ≤100mA
  • LED indicator
  • Wiegand 26bits (Wiegand34,RS232 should be customized)

Access Control RFID Card Reader With Keypad PY-CR49



Feature

• Read Range: Up to 10CM(125KHz)/5CM( MIFARE®)
• 2Wiegand 26bits (Wiegand34,RS232 should be customized)
• External LED Control
• External Buzzer Control
• Indoor / Outdoor Operation
• Solid Epoxy Potted
• Reverse Polarity Protection



Specification:

Model EM MIFARE®
Read Range Up to 10CM Up to 5CM
Reading Time (Card) ≤300ms
Power / Current DC 9-12V / ≤100mA
Input Port 2ea (External LED Control, External Buzzer Control)
Output Format 26bit Wiegand (default) Wiegand34,RS232 should be customized
LED Indicator 2 Color LED Indicators(Red and Green)
Beeper Yes
Operating Temperature -20° to +65°C
Operating Humidity 10% to 90% relative humidity non-condensing
Color Black
Material ABS+PC with texture
Dimension
(W x H x T)mm
120×56×20

Wire Connection
Red           DC 5V-16V
Black        GND
Blue          D1
White        D0
Brown        BEEP
Green        LED
Yellow       Alarm
